Description
Rich Solar's Cable Entry Plate is a power-accessory designed for reliable off-grid and backup power applications, rated for 0.1kW systems. It features pre-installed, IP68 waterproof MC4 connectors within a durable polypropylene housing built for challenging outdoor environments.
This accessory is suited for installers and system builders needing a secure, weatherproof cable entry solution that supports up to 30A continuous current with UL-certified wiring.
Features
- 30A/600V Rating: UL1015-certified 10AWG tin-plated copper wires
- Tool-Free MC4 Connectors: Pre-installed, IP68 waterproof, and UL94V0 flame-retardant
Specifications
General
- Dimensions (L×W×H): 5.9×4.3×1.6 in
- Weight: 0.29 lb
- Material: Flame-Retardant Polypropylene (PP)
- Color: Black
- Operating Temperature: -40°C to 85°C (-40°F to 185°F)
MC4 Connector Details
- Material: PC Shell
- Waterproof Rating: IP68
- Flame Retardant: UL94V0 Certified
- Certification: UL Listed
Electrical Ratings
- Maximum Current: 42A
- Continuous Current: 30A
- Maximum Voltage: 600V (Wire Rating)
- Wire Standard: UL 1015 10AWG (Red/Black)
- Wire Conductor: Tin-Plated Copper
- Wire Insulation: PVC (VW-1 Fire Rated)
- Wire Temperature Range: -15°C to 105°C (5°F to 221°F)
