Rich Solar BRAVO AIR 30 | 30A Flush Mount PWM Solar Charge Controller | Bluetooth & Multi-Protection | Premium 12V 30A Controller
SKU: RS-PWM30PF
AVAILABILITY:
Out of stock
See a Lower Price?
Let us know and we’ll match it. Get the best price — Guaranteed!
Choose options
AVAILABILITY:
Out of stock
See a Lower Price?
Let us know and we’ll match it. Get the best price — Guaranteed!
Description
The Rich Solar BRAVO AIR 30 is a 30A flush mount PWM solar charge controller designed for reliable battery management in RVs, campers, vans, and boats. This controller offers multi-stage intelligent charging and Bluetooth connectivity for remote monitoring, improving system oversight and efficiency.
Engineered to protect against common electrical faults including over-voltage and reverse polarity, it supports multiple battery chemistries like LiFePO4 and AGM, making it a practical choice for various off-grid power setups.
Features
- PWM + MOSFET for efficient, stable output
- Intelligent multi-stage charging
- Auto BMS activation for lithium batteries
- Built-in Bluetooth for remote monitoring
- Battery type selection, with real-time display and LED status indicators
Specifications
Electrical Parameters
- Rated solar panel amps: Max. 30 A
- Normal input solar cell array voltage: Max. 5~22 VDC
- Maximum solar cell array voltage (output has no load): Max. 25 VDC
- The controller's lowest operating voltage at the solar or battery side: Min. 8 VDC
- Standby current consumption at night: Max. 10 mA
- Maximum voltage drop – Solar panel to battery: Max. 0.25 VDC
Protection
- Against reverse polarity or short circuit at the panel or battery
- Over temperature protection during charging: 185°F / 85°C
Environmental Characteristics
- Operating temperature: -13 ~ 122°F / -25 ~ 50°C
- Storage temperature: -40 ~ 185°F / -40 ~ 85°C
- Operating humidity range: 0–85% RH
Physical Parameters
- Controller material: Plastic (PC)
- Power terminal max. wire size: #8 AWG stranded – 0.2 in²
- Power terminal torque: 6.2–7.1 in-lb (0.7–0.8 N·m)
- Mounting: Vertical wall mounting
- IP grade: IP22
