Rich Solar BRAVO 60 | 60A MPPT Solar Charge Controller | Premier 60A 12V/24V MPPT Solar Controller

Description

Rich Solar Bravo 60 is a premium MPPT solar charge controller designed as a controller for off-grid systems in RVs, campers, boats, and trailers. It supports 12V and 24V batteries with a max PV charging current of 60A, optimizing solar input up to 1800 watts.

Ideal for users who need precise and efficient battery management, this controller adapts to multiple battery chemistries including lead acid and lithium, enabling reliable solar charging tailored to diverse off-grid setups.

Features

• True MPPT
• Tracking Efficiency Above 99.5%
• Charge Conversion Efficiency as High as 98%
• 12V/24V DC System Self-Adaptation
• Reverse Discharge Protection
• Targeted for Accuracy
• Overvoltage Protection
• Common Negative Connection
• Charging Data Storage
• External Battery Temp Sensor-Optional
• Conformal Coating for Inside Board
• External Digital Remote Display-Optional
• In-house Design and Manufacture
• Extensive Internal Electronics, In-Circuit Protections, and Safety Protections
• Targeted for Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
• Targeted for Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections

Specifications

• System Nominal Voltage: 12/24V Auto
• Max PV Open Circuit Voltage: 100V DC
• Charging Technology: MPPT
• Max PV Charging Current: 60A
• Max. Recommended PV Input Power: 900 Watt (12V) / 1800 Watt (24V)
• Charge Conversion Efficiency: ≤98%
• MPPT Tracking Efficiency: >99.5%
• Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
• Housing Case Color: Black / Grey
• IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
• Net Weight: 1.90kg / 4.18lb
• Dimensions (L×W×H): 201×195×85mm (7.9×7.7×3.3in)

Downloads

• Download Manual (PDF)
• Download Specification Sheet (PDF)
